| Basic Parameters: |
|
CV205W |
CV205U |
CV205X |
| Display Technology |
3LCD x 0.59" Sony Policilicon |
3LCD x 0.64" Sony Policilicon |
3LCD x 0.63" Sony Policilicon |
| Native Resolution |
WGA/ 1280 x 800 Pixels(CV205AW) |
WUXGA/ 1920 x1200 Pixels(CV205AX) |
XGA/ 1024 x 768 Pixels(CV225AX) |
| Max. Computer Input |
UXGA |
UXGA |
UXGA |
| Brightness |
5000 ANSI Lumens (Std) |
5000 ANSI Lumens (Std) |
5000 ANSI Lumens (Std) |
| Zoom Ratio |
1.65x optics |
| Contrast |
5000:1 Contrast Ratio by VGA terminals,dynamic contrast ratio up to 10000:1 |
| Noise Level |
20/45dB (ECO/BRIGHT mode) |
| Aspect Ratio |
4:3 Native, 16:9 Compatible |
| Projection Method |
Front, Rear,Ceiling,Table Top;Projection Image support horizontal and vertical flip |
| Weight |
3.7 kg |
| I/O Connectors |
Inputs: |
HDMI 1.4 *2;VGA*1;ideo*1;USB-A*1;USB-B(display)*1;RS232*1;RJ45*1;RJ45(display)*1; |
| Outputs: |
VGA Out x 1,Audio output x 1 |
| Control: |
RS232 x 1 |
| Preset Mode |
PC: |
For computer or notebook (Brightest image) |
| Movie: |
Maximum contrast and Colour accuracy |
| Game: |
Bright vivid colour |
| sRGB: |
For Standard PC Colour (Best Colour Reproductiion) |
| User: |
Memorises user's settings |
| Maximum Resolution |
UXGA 1600 x 1200 Pixels via HDMI |
| Video Compatibility |
PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080P, 720p) |
| Displayable Colours |
1.07 Billion |
| Projection Lens |
Normal throw lens /F:1.6-2.08; f=19.36-31.94mm, *1.65 Zoom,70’‘ at 2.11 m . |
| Throw Ratio |
70’‘ at 1.904m , 1.26-2.09:1 |
| Projection Screen Size |
0.9m - 15.2m（30"~300"）Diagonal 4:3 |
| Projection Distance |
09 - 15.2 metres |
| Horizontal Scan Rate |
15.3 -100kHz |
| Vertical Scan Rate |
48 - 85Hz |
| Lamp Type/Lamp Life |
225W, 10000/20000 hours (ECO/BRIGHT mode) |
225W, 10000/20000 hours (ECO/BRIGHT mode) |
225W, 10000/20000 hours (ECO/BRIGHT mode) |
| Keystone Correction |
± 30° Vertical H:±15° (manual) Corner Keystone,Barrel (XGA and WXGA ) |
| Dimensions (W x D x H) |
345 x 261 x 100 mm |
| Remote Control |
Full function remote with direct source selecting |
| Power Supply |
100-240V, 50-60Hz |
| Power Consumption |
38 0W BRIGHT mode < 1W Standby mode, 350W STD mode < 1W Standby mode |
| Operating Conditions |
5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m |
| Uniformity |
90% |
| Security |
Kensington Lock, Password Protection |
| Standard Accessories |
AC Power Cord,VGA Cable, Remote Control,Quick Start Card,CD User Manual, Warranty Card |
| Optional Accessories |
Ceiling Mount Kit, Additional Ultra long Cable |
| Warranty |
Projector 3-Years,lamp six months or 500Hrs |
