| Model |
CVDP1020+ |
CVDP1030+ |
CVDP1040+ |
| Display Technology |
DLP DMD 0.67 |
DLP DMD 0.67 |
DLP DMD 0.67 |
| Native Resolution |
WUXGA 1920* 1200 |
| Brightness |
15,000 ansi lumens |
18,000 ansi Lumens |
20,000 ansi Lumens |
| Contrast |
100000:1 Contrast Ratio |
| Fan Noise |
As low as 27 dBa |
| Aspect Ratio |
16:10 Native,16:9 Compatible |
| Projection Method |
Front, Rear,Ceiling,Table Top;Projection Image support horizontal and vertical flip |
| Weight |
30 kg |
| I/O Connectors |
HDMI*1,3D-SDI in/out*2 ,3D-SYNC in/out *2 ,DVI-D*1,VGA in/out*2,USB-A*1,HD-BaseT*1,RS232*1,RJ45*1,3D active |
| Maximum Resolution |
4K via HDMI Terminal |
| Displayable Colours |
1.07 Billion |
| Projection Lens |
0.38:1 |
| 0.76-0.95:1 |
| 1.14-1.71:1 |
| 1.61-2.42:1（STD） |
| 2.37:3.6:1 |
| 3.53-5.65:1 |
| |
5.52-8.83:1 |
| Throw Ratio |
1.61-2.42:1 (STD) |
| Projection Distance |
1.025-25.48m(Standard Power Lens ) |
| Lamp Type/Lamp Life |
1300W Roller type laser light source, 20000 hours life |
| lens shift |
±120° Vertical ± 50° Horizontal manual |
| keyston correction |
V+H |
| Dimensions (W x D x H) |
590x560x188 mm |
| Remote Control |
Full function remote with direct source selecting |
| Power Supply |
100-240V, 50-60Hz |
| Power Consumption |
1460W |
| Operating Conditions |
5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m |
| Uniformity |
0.9 |
| Standard Accessories |
AC Power Cord,VGA Cable, Remote Control,Quick Start Card,CD User Manual, Warranty Card |
| Optional Accessories |
Ceiling Mount Kit, Additional Ultra long Cable |
| Guarantee |
5 years |
| Outstanding Features |
● 20,000 ANSI Lumens bright, with 90% uniformity and a 100000:1 Contrast Ratio.
● DLP DMD 0.67 imaging for rich, color saturated computer and video projection.
● 24*7 hrs long time working without problem.
● No weaken on brightness after 3 years usage.
● Optional wide-angle and telephoto lenses. Instant lens change system.
● 1 seconds for turn on the projector,fast then other type in this area.
● Includes most professional input configurations, including BNC and DVI.
● Vertical and Horizontal power lens shift and digital keystone correction.
● 16-bit color reproduction for superior color reproduction.
● Support PJlink/Telnet/Crestron View control.
● DLP Active 3D ready for entertainment.
● 360 degree installation.
● Custom warm-up screen option. Built-in Color Auto Picture Control.
● Built-in network(RJ45) monitoring and control. Optional network content delivery.
● 5 year projector warranty! |
|
